XLPE Insulated Cable

MOQ:	100 metros
Precio:	USD 3.76-7.68/M
Embalaje Estándar:	Tambor de madera
Período De Entrega:	7 días
Método De Pago:	L/C, T/T,
Capacidad De Suministro:	436970KM/Week

Detalles Información

Descripción del Producto

Información detallada

Lugar de origen

China

Nombre de la marca

QINGDAO YICABLE CABLE

Certificación

KEMA/CE/ISO/TUV/RoSH

Material de la pantalla:

cinta de cobre

Tensión nominal:

6.35/11kV

Chaqueta:

PVC

Muestra:

libre

Pruebe el voltaje:

3.5KV

Temporeros de funcionamiento:

90 grados

Marca del cable:

Impresión o grabación en relieve

mercado principal:

Asia, África

Resaltar:

xlpe power cable

cross linked polyethylene cable

Descripción del Producto

Three Core Copper Conductor XLPE Insulated Medium Voltage 11kV Power Cable

Constructions

Conductor : Compact stranded copper conductor, Cl.2 as per IEC 60228

Conductor Screen: Semi-conductor

Insulation : XLPE(cross-linked polyethylene) rated at 90 OC

Insulation Screen: Semi-conductor

Screen : Copper tape

Sheath : PVC or FR-PVC type ST2 to IEC 60502, black

Note: Insulation color as per standards or customer requirement

Applications

For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.

Standards

International: IEC 60502, IEC 60228

China: GB/T 12706.1-2008

Other standards such as BS,DIN and ICEA upon request

Technical data

Rated voltage:6/10kV

Maximum Conductor Temperature: under normal (90^OC), emergency (130^OC) or short circuit no more than 5 s (250℃) conditions.

Min. Ambient Temp. 0^OC, after installation and only when cable is in a fixed position

Min. Bending Radius: 20 x cable O.D for single core

15 x cable O.D for multi core

Certificates

CE, RoHS, CCC, KEMA and more others at request

Technical Specifications

Nom. Cross-section of conductor	Strands No./Dia. Of Conductor	Insulation Thickness	Sheath Thickness	Approx. O.D.	Approx.Weight	Max. D.C Resistance of Conductor (20 ℃)	Testing Voltage A.C	Current Rating
mm²	pc/mm	mm	mm	(mm)	kg/km	Ω /km	kV/5min	In air (A)	In soil(A)
1 × 25	7/2.14	4.5	1.8	23.0	598	0.727	30.5	140	150
1 × 35	7/2.52	4.5	1.8	24.0	680	0.524	30.5	175	180
1 × 50	10/2.52	4.5	1.9	25.0	804	0.387	30.5	205	215
1 × 70	14/2.52	4.5	1.9	27.0	984	0.268	30.5	260	265
1 × 95	19/2.52	4.5	2	29.0	1201	0.193	30.5	315	315
1 × 120	24/2.52	4.5	2	30.0	1490	0.153	30.5	365	360
1 × 150	30/2.52	4.5	2.1	32.0	1765	0.124	30.5	415	405
1 × 185	37/2.52	4.5	2.1	34.0	2091	0.0991	30.5	475	455
1 × 240	48/2.52	4.5	2.2	36.0	3034	0.0754	30.5	565	530
1 × 300	61/2.52	4.5	2.4	39.0	3672	0.0601	30.5	645	595
1 × 400	61/2.97	4.5	2.4	42.0	4646	0.0470	30.5	750	680
1 × 500	61/3.23	4.5	2.5	45.0	5651	0.0366	30.5	865	765
1 × 630	61/3.50	4.5	2.5	50.0	7154	0.0283	30.5	990	860
1 × 800	91/3.20	4.5	2.7	55.0	8750	0.0221	30.5	1140	950
1 × 1000	91/3.75	4.5	2.9	59.0	10727	0.0176	30.5	1250	1040
3 × 25	7/2.14	4.5	2.4	46.0	2573	0.727	30.5	120	125
3 × 35	7/2.52	4.5	2.6	48.0	2985	0.524	30.5	145	155
3 × 50	10/2.52	4.5	2.7	51.0	3529	0.387	30.5	175	180
3 × 70	14/2.52	4.5	2.8	55.0	4197	0.268	30.5	220	220
3 × 95	19/2.52	4.5	2.9	58.0	5230	0.193	30.5	265	265
3 × 120	24/2.52	4.5	3.0	61.0	6120	0.153	30.5	305	300
3 × 150	30/2.52	4.5	3.1	64.0	7207	0.124	30.5	350	340
3 × 185	37/2.52	4.5	3.2	68.0	8378	0.0991	30.5	395	380
3 × 240	48/2.52	4.5	3.4	73.0	10177	0.0754	30.5	470	435
3 × 300	61/2.52	4.5	3.5	77.0	12159	0.0601	30.5	535	485
3 × 400	61/2.97	4.5	3.8	86.0	15641	0.0470	30.5	610	520

Ordering Advice

Rated Voltage

Application Standard: IEC/BS/UL/GB

Number of Cores

Conductor Size & Construction

Type of Insulation

Armored or unarmored. If armor, the armor type & material

The Requirement of Sheath

Length of Cable & Packing Requirement

Etiquetas:
