BS 6724 Unarmoured LSZH Low Smoke Zero Halogen Cable Basec Multi Core0.6/1KV 4Cx185SQMM

MOQ:	100m
Precio:	USD 1.12-8.99/M
Embalaje Estándar:	Tambor de madera
Período De Entrega:	7 días
Método De Pago:	L / C, T / T
Capacidad De Suministro:	38573KM/Day

Detalles Información

Descripción del Producto

Información detallada

Lugar de origen

China

Nombre de la marca

QINGDAO YICABLE CABLE

Certificación

RoHS/KEMA/TUV/CE/ISO

conductor:

cobre trenzado

Pruebe el voltaje:

3.5KV

Aislamiento:

XLPE

Temporeros de funcionamiento del conductor:

℃ 90

Tensión nominal:

600/1000V

color:

Naranja

Resaltar:

low smoke zero halogen wire

xlpe lszh cable

Descripción del Producto

BS 6724 Unarmoured LSZH Low Smole Zero Halogen Cable Basec Multi Core0.6/1KV 4Cx185SQMM

Conductor: Class 1/2 annealed bare copper solid or strands. This wires are formed into final conductor in the stranding machines under strict quality surveillance.

Insulation: Cross linked polyethylene compound or PVC is insulated over the conductors by extrusion process.The raw materials and thicknesses of Insulation are maintained as per standards and conform to IEC60502/BS7870 Standards as the case may be.

XLPE:Insulated Power Cable are identified either by colour or by numbers as follows:
No. of cores Identification
Old Colour coding New Colour coding as per requirement

Armour : When armouring is required, the armour consists of single layer of galvanised steel wires/galvanized steel tapes.
The armour is applied helically as per standards.
Single core cables are armoured with Aluminium Wires or Copper wires based on requirement.

Outer sheath : Standard cables are manufactured with Extruded black PVC. Outersheath is embossed or printed with the information required by relevant standards.
Special FR, FRLS, FRRT, LSF, MDPE compounds are used for outersheathing of cables, to suit customer’s specific requirements.

Standards

International: IEC 60502, IEC 60227 IEC 60331, IEC 61034

China: GB/T 12706-91 GB306.1-2001, GB/T18380.3-2001

Other standards such as BS,DIN and ICEA upon request

Technical data

Rated voltage: 0.6-1kV

Max. Conductor Temp.:normal (90℃), short circuit no more than 5 s (the highest temperature of conductor shall no more than 250°C )

Min. Ambient Temp.:The cable shall be pre heated if the ambient temperature is below 0°C

Min. Bending Radius: single core cable 20(d+D)±5% ,Multi-core cable 15(d+D)±5%

Nom. Cross-section of conductor	Insulation Thickness	Sheath	Approx.	Approx	Max. D.C. Resistance of Conductor (20°C)	Test Voltage	Current Rating
mm2	mm	Thickness	O.D.	Weight	Ω/km	A.C	Current Rating
		mm	mm	kg/km		kV/5min	In air(A)	In soil(A)
4×1.5	0.7	1.8	14.4	241	12.1	3.5	20	27
4×2.5	0.7	1.8	15.4	295	7.41	3.5	26	35
4×4	0.7	1.8	16.5	369	4.61	3.5	34	45
4×6	0.7	1.8	17.8	463	3.08	3.5	43	57
4×10	0.7	1.8	20.9	667	1.83	3.5	60	77
4×16	0.7	1.8	23.4	930	1.15	3.5	83	105
4×25	0.9	1.8	27.1	1351	0.727	3.5	105	125
4×35	0.9	1.8	29.5	1772	0.524	3.5	125	155
4×50	1	1.9	38.4	2380	0.387	3.5	160	185
4×70	1.1	2	43.2	3302	0.268	3.5	200	225
4×95	1.1	2.2	47.3	4330	0.193	3.5	245	270
4×120	1.2	2.3	52.5	5374	0.153	3.5	285	310
4×150	1.4	2.5	58.3	6655	0.124	3.5	325	345
4×185	1.6	2.7	64.7	8246	0.0991	3.5	375	390
4×240	1.7	2.9	73.1	10569	0.0754	3.5	440	450
5×1.5	0.7	1.8	13.6	284	12.1	3.5	20	27
5×2.5	0.7	1.8	16.6	349	7.41	3.5	26	35
5×4	0.7	1.8	17.9	441	4.61	3.5	34	45
5×6	0.7	1.8	19.3	558	3.08	3.5	43	57
5×10	0.7	1.8	22.8	809	1.83	3.5	60	77
5×16	0.7	1.8	25.6	1135	1.15	3.5	83	105
5×25	0.9	1.8	29.7	1664	0.727	3.5	105	125
5×35	0.9	1.9	32.6	2194	0.524	3.5	125	155
5×50	1	2	37.3	3013	0.387	3.5	160	185
5×70	1.1	2.1	42.9	4101	0.268	3.5	200	225
5×95	1.1	2.2	48.2	5382	0.193	3.5	245	270
5×120	1.2	2.4	52.7	6685	0.153	3.5	285	310
5×150	1.4	2.5	58.5	8363	0.124	3.5	325	345
5×185	1.6	2.7	65.1	10268	0.0991	3.5	375	390
5×240	1.7	3.1	72.3	13167	0.0754	3.5	440	450

Packaging Material:

Steel wooden drum (fumigation)

Cable length in each drum: 500m/1000m or as per actual cable length requirements.

Drum Size:

As per cable length and container size

*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

Port: Shanghai,China, or other ports as per your requirements.

Sea freight: FOB/C&F/CIF quotation are all available.

BS 6724 Unarmoured LSZH Low Smoke Zero Halogen Cable Basec Multi Core0.6/1KV 4Cx185SQMM 0
